Ultra Light 9 kgMIJO MT07 8″ Ultra-Lightweight Electric Handbike for Fixed Leg Wheelchair
8-Inch Ultra-Lightweight (9 kg) Power Attachment with Two-Sided Connector for Fixed-Leg Wheelchairs
Engineering & Clinical Highlights
- Featherweight 9 kg chassis allows effortless lifting by elderly users or caregivers into passenger vehicle trunks.
- Equipped with Two-Sided Clamping System designed specifically for fixed-leg rigid manual wheelchairs.
- High-efficiency 36V 350W brushless motor providing swift urban speed up to 20 km/h.
- Removable 36V 7.8Ah lithium battery offering up to 35 km cruising range per charge.
- Ultra-compact folding geometry complies with airline transport and high-speed rail luggage requirements.
- Equipped with motorcycle-grade disc brake and bright LED multi-function display.
Verified Specifications & Factory Capabilities
Comprehensive mechanical benchmarks, wheelchair frame fitment standards, and private label customization for authorized distributors.
Wheelchair Compatibility
| Wheelchair Type | Manual Wheelchairs with Fixed Front Legs / Rigid Frame |
|---|---|
| Connector Type | Patented Lightweight Two-Sided Clamping Brackets |
| Compatible Tube Diameter | 20 mm - 35 mm |
| Compatible Brands | Quickie, TiLite, OttoBock, Invacare, Sunrise Medical, Panthera, RGK, Kuschall |
Electrical & Performance
| Motor Power | 36V 350W High-Efficiency Brushless Hub Motor |
|---|---|
| Battery Pack | 36V 7.8Ah Lithium-ion Battery with Anti-Theft Lock |
| Speed Levels | 1st: 8 km/h | 2nd: 15 km/h | 3rd: 20 km/h |
| Climbing Ability | 0 - 8 degrees slope |
| Operating Range | 30 - 35 km per charge |
| Charging Time | 4 - 6 hours with Smart Charger |
| Controller | Intelligent FOC Sine-Wave Controller |
Mechanical & Physical
| Drive Wheel Size | 8-Inch Solid / Pneumatic Tire with Aluminum Rim |
|---|---|
| Overall Dimensions | 900 mm x 480 mm x 880 mm |
| Net Weight | 9.0 kg (including battery) |
| Max Rider Weight | 120 kg (264 lbs) |
| Brake System | Disc Brake + Motor Electronic Cut-off |
| Suspension | Internal Front Spring Damper |
| Handlebar | Quick-Folding Telescopic Handlebar |
B2B Packaging & Logistics
| Export Carton Size | 940 mm x 420 mm x 380 mm |
|---|---|
| Gross Weight | 11.8 kg (reinforced 7-ply export carton with custom foam) |
| 20GP Container Load | 200 Units |
| 40HQ Container Load | 490 Units |
Professional Overview: MIJO MT07 8″ Ultra-Lightweight Handbike
At just 9.0 kg including battery, the MIJO MT07 is one of the lightest, most portable powered wheelchair attachments in the global market. Engineered specifically for active individuals who travel frequently by car, train, or airplane, the MT07 folds down in seconds and can be hoisted into any standard car trunk with one hand.
Equipped with our proven Two-Sided Clamping Brackets, the MT07 attaches securely to fixed-leg rigid manual wheelchairs. Despite its featherweight footprint, its 350W motor and 36V 7.8Ah lithium battery provide 35 km of range and reliable 20 km/h speed, making it an essential urban mobility solution for global distributors.
Wheelchair Clamping & Model Selection Guide
Understanding the two distinct connector types ensures 100% fit for your clients. We engineer dedicated docking hardware for both rigid fixed-frame wheelchairs and folding wheelchairs with swing-away footrests.
Two-Sided Clamping System
Designed for manual wheelchairs with fixed front downtubes.
How It Works:
Two precision-machined 6061-T6 aluminum clamps fasten directly onto the left and right front frame tubes (diameters 20mm to 35mm). Quick-cam levers allow 5-second toolless docking.
Ideal Wheelchair Types:
- Rigid box-frame and open-frame active wheelchairs
- Fixed front downtubes without detachable footrests
- Popular models: Quickie (Nitrum, 7R), TiLite (ZR, ZRA, Aero T), OttoBock Zenit, Küschall, Panthera
Intermediate Central Connector
Designed for wheelchairs with swing-away or removable footrests.
How It Works:
An adjustable transverse bracket mounts solidly beneath the seat frame, leaving the front legs completely unencumbered. Riders can swing away or remove footrests normally for easy standing transfers.
Ideal Wheelchair Types:
- Folding X-frame manual wheelchairs with swing-away legrests
- Elderly or rehabilitation wheelchairs requiring clear frontal leg access
- Popular models: Invacare (Action series), Sunrise Medical (Breezy), OttoBock (Start), Drive Medical, Karma
We support custom engineering tailored to your regional compliance standards, private label brand requirements, and hospital tenders.
Custom Frame Colors & Coatings
Anodized titanium, racing red, hospital white, or custom RAL powder-coating with corrosion-resistant treatment.
Laser Logo & Hardware Badging
High-precision fiber laser engraving on clamp arms and handlebar stems. Private label user manuals and serial number plates.
Controller & Speed Firmware
Pre-programmed speed profiles (6 km/h, 15 km/h, 25 km/h) to meet specific national road authority and medical reimbursement regulations.
Export Packaging & Palletizing
Heavy-duty drop-tested master cartons optimized for international ocean container loading (20GP / 40HQ) and air freight protection.
CE MDR 2017/745 Class I
Certified Class I medical device attachment for active wheelchairs under European Medical Device Regulation (EU) 2017/745.
ISO 13485:2016 Certification
Manufactured in certified medical device clean facilities with full trace records and incoming component QC verification.
2026 Technical Specification Sheet
Complete dimensional CAD blueprints, electrical torque curves, and container packing specifications in PDF format.
24 Months Full B2B Coverage
Expedited air courier replacement for electrical and mechanical components with zero customer downtime guarantee.
View Full Warranty Terms →Q1Which wheelchairs are compatible with the MIJO MT07 8″ Ultra-Lightweight Electric Handbike for Fixed Leg Wheelchair?
The MIJO MT07 8″ Ultra-Lightweight Electric Handbike for Fixed Leg Wheelchair (MT07) attaches to manual wheelchairs with 20mm-35mm frame tube diameters using Mijo patented quick-release clamps. It fits rigid frame wheelchairs as well as folding chairs with standard adapter hardware.
Q2What is the wholesale minimum order quantity (MOQ) and production lead time for MT07?
We support 1-unit functional sample evaluation orders for clinical fitment and road testing (7-10 Days Sample / 25-30 Days Bulk Container). For wholesale distributor container orders, the standard MOQ is 1 Unit (Sample) / 5 Units (Wholesale OEM) with a 25-30 day manufacturing cycle.
Q3Does the MT07 have medical and lithium battery transport certifications?
Yes, the MT07 complies with ISO 13485:2016 Medical Quality, CE MDR 2017/745 Class I, EN 12184:2014 Standard, UN38.3 Flight Travel Safety. All lithium battery assemblies include UN38.3 test summaries and MSDS documentation for seamless air express and ocean freight customs clearance.
Q4Can distributors order the MT07 with custom branding and regional speed limits?
Yes. We provide turnkey OEM/ODM services including laser-etched distributor logos, custom RAL color powder-coating, localized user manuals, and intelligent controller firmware programming to enforce 6 km/h, 15 km/h, or 25 km/h territory speed limits. All units come with a 24-month factory warranty.
